· If an error occurs before transmitting the identification result, the printer does not
transmit the identified result.
· When DTR/DSR control is selected, the printer transmits data consecutively after
confirming whether the host computer is ready to receive data. When the host is
not ready to receive data, the printer waits until the host is ready.
· When XON/XOFF control is selected, the printer transmits all data consecutively
without confirming whether the host computer is ready to receive data. The data
transmission must be consecutive, except for the XOFF code.
· The printer transmits all data collectively without confirming whether the host is
ready to receive data. To receive all data correctly, 67 bytes or more space is
required in the receive buffer.
· During identification result transmission, the printer ignores
DLE EOT
n
and
DLE
EOT BS
n
. Also, the printer does not transmit ASB even when the ABS is
enabled. Therefore, the user cannot confirm changes in the printer status during
these periods.
· It is possible to differentiate the reading results of MICR, ASB, and real-time
status. Refer to Appendix E for data identifying method.
· The identification result is not cleared until: the next
FS a 0
is executed,
ESC @
is executed,
FS q
is executed, the printer is reset, or the printer power is
turned off.
· Data transmission (real-time commands and the like) should not be executed
during MICR reading, because it affects the reading precision and may lower the
recognition rating.
· If the printer receives
FS a 1
,
FS a 2
, or
FS b
when bit 5 is 0 (normal end), the
printer executes each command. If the printer receives any other code (except
for real-time commands), the printer ejects the check, ends MICR function, and
selects the paper roll.
· Paper feeding with the FORWARD/REVERSE button and auto loading cannot be
executed during the period from starting MICR character reading to ending check
paper ejection. Also, do not change the ink ribbon during this period.
[Reference]
DLE EOT BS
,
DLE ENQ
,
ESC f
,
FS a 1
,
FS a 2
, Appendix E
