Epson TM-H5000II series User Manual

CONFIDENTIAL
24
SHEET
App. 24
NO.
SHEET
REVISION
E
TITLE
NEXT
App. 2
5
TM-H5000
II
IIII
II
series
Specification
(STANDARD)
APPENDIX K COMPARISON TABLE BETWEEN TM-H5000
II
IIII
II
AND TM-H5000
TM-H5000
II
TM-H5000
1. Printing speed for receipt
High speed mode
Low speed mode
ladder bar code
120 mm/sec maximum
--
Approximately 42 mm/sec
Approximately 70 mm/sec
Approximately 50 mm/sec
Approximately 35 mm/sec
2. Font B for receipt
9 ´ 17 dots 9 ´ 24 dots
3. Life of print head (for slip) 200 million characters
(when printing font B)
150 million characters
(2dots/wire per character
average)
4. NV bit image buffer area 384K bytes None
5. User NV memory 1K bytes Not supported.
6. Low power consumption
mode (for receipt)
When DIP switches 2-3 and 2-4 are set
to ON, printing speed is fixed to 70
mm/sec. In this mode, the power
consumption is almost same as the
TM-H5000.
None
(When DIP switches 2-3
and 2-4 are set to ON
respectively, the most light
of print density is set.)
7. Adaptability to high speed
parallel interface board
Possible with a combination of Epson
original parallel interface board
Impossible
8. Commands
DLE DC4
: Generate pulse at real time
ESC M
: Select character font
FS g 1
: Write to user NV memory
FS g 2
: Read from user NV memory
FS p
: Print NV bit image
FS q
: Define NV bit image
GS ( A
: Execute test print
GS g 0
: Initialize maintenance
counter
GS g 2
: Transmit maintenance
counter
9. Multilingual support
Japanese Kanji
Chinese Kanji
Taiwanese Kanji
Thai character
Depending on the model type, one of
these character is supported.
Japanese Kanji only
END
