Specification
(STANDARD)
GENERAL DESCRIPTION
The TM-H5000
II
is a high-quality POS printer that can print on slip and receipt paper (paper roll).
This specification applies the following models of the TM-H5000
II
series printer:
TM-H5000
II
(with serial interface)
TM-H5000
II
P (with parallel interface)
TM-H5000
II
M (supporting Multilingual characters with serial interface) (*1)
TM-H5000
II
PM (supporting Japanese Kanji characters with parallel interface)
The printer has the following features:
<Slip Section>
·
Wide slip paper capability (maximum characters per line: 88 with 7 x 9 font).
·
Copy printing is possible.
·
High throughput using bidirectional, minimum distance printing.
·
Optional Magnetic Ink Character Recognition (MICR) reader that enables the printer to perform consecutive
reading and processing of MICR characters and printing endorsements.
<Receipt section>
·
High speed printing with collective printing.
·
The standard auto-cutter provides easy user operation.
·
Ladder bar code printing is possible by using a bar code command.
·
New paper handling enables easy paper roll setting.
<Both Receipt and Slip>
·
EPSON customer display series connection (DM-D). (Available only for serial interface model)
·
Selectable receive buffer size (45 bytes or 4K bytes).
·
Command protocol based on the ESC/POS® standard.
·
Automatic Status Back (ASB) function that automatically transmits changes in the printer status.
·
Available NV (non-volatile) bit image buffer size (384 Kbytes).
·
User NV (non-volatile) memory size (1K byte).
NOTE *1: Multilingual characters means that the printer can print with one of Japanese Kanji,
Chinese Kanji, Taiwanese Kanji or Thai characters. In this specification, Kanji (Chinese
character) means Japanese, Chinese, and Taiwanese characters.
