14.13 Technical data
General
Nominal supply voltage: 24 V DC from front
Supply voltage range: 19.2 V to 30 V, according to EN 61131-2
Max. switch-on current: 12 A
Equipment class: III according to EN 61131-2
Galvanic isolation: No
Max. total power consumption: 69 W
Power consumption own consump-
tion:
14 W
Max. power output K-Bus 24 V: 45 W
Max. power output K-Bus 5 V: 10 W
Ventilator: No outside ventilation, no ventilator
Environmental conditions
Operating temperature: +5 °C to +55 °C
Storage temperature: -40 °C to +70 °C
Relative humidity of air: 10 % to 95 % (non condensing)
Vibration resistance: According to EN 61131-2:2007
Shock resistance: According to EN 61131-2:2007
Computer kernel
Processor: Embedded Processor ~400 MHz
Memory: 64 MB
Buffered SRAM: 512 kB
Interfaces
CAN interface onboard: Communication with periphery components
CAN bus Baud rates: To be set via software
Serial interface onboard: RS-485-A
RS-485-A Baud rates: To be set via software
Extension for one:
Serial interface: Via CECX-C-S1 or CECX-S-S4
CAN interface: Via CECX-F-CO
Ethernet interface: Via CECX-C-ET
USB: USB 1.1, 10 Mbit / 0.5 Mbit
Compact Flash: Type 1
Dimensions:
Footprint:
Height: 120 mm
Width: 180 mm
Depth: 100 mm
Weight: 580 g
Type of assembly: Mounting rail
Protection class: IP20
CECX-II 14-24
