System manual CECX / Temperature module CECX-E-4E-T-P1
CECX-II 23-3
23.3 Description of the module
The CECX-E-4E-T-P1 is a temperature module for use in the CECX modu-
lar control system. The CECX-E-4E-T-P1 module allows direct connection
of PT100 resistance sensors. Up to 4 temperature measurement modules
can be operated in 2- or 4-conductor technique.
23.3.1 Front view
000102030405060708091011121314151617
IRF0
GND
IRF1
+
-
TI1
+
-
TI0
GND
IRF2
GND
IRF3
+
-
TI3
+
-
TI2
GND
GND
GND
CECX-E-4E-T-P1 front view
Information
The type plate is stored on the module in an EEPROM and can be read out
by the application.
