Festo CECX-X-C1 Series User Manual

System manual CECX / System overview
3.2.3 Internal memory of the CECX modular control system
The available memory of the CECX modular control system is divided au-
tomatically under CoDeSys.
Please adhere to the following maximum sizes:
Memory Description Value
Code Working memory to execute the user
programs
6,144 KByte
Global data Data memory for IEC project 18,432 KByte
Marker Marker memory 8 KByte
Inputs Input map memory 8 KByte
Outputs Output map memory 8 KByte
Retain Battery-buffered SRAM 128 KByte
Marker-variables and retain-data are stored in different memories. Because
of this it is not possible to mark a retain variable.
3.3 Start-up and programming (overview)
The CoDeSys 2.3 development environment serves for the start-up and
programming of the CECX modular control system.
CoDeSys offers a comfortable user interface with the following functions:
 Configuration and parameterization of the CECX modular control sys-
tem (with the control configuration)
 Programming according to EN 61131-3 (see chapter Programming lan-
guages)
 Integrated module libraries (see Description of library)
 Library administrator for integrating additional libraries
 Simulation mode (enables projects to be tested on the PC without PLC)
 Documentation (integrated project documentation)
 Debugging function (testing program sequence, monitoring and modify-
ing variables, error search).
To enable a control (target system) to be used under CoDeSys a so-called
target support package is required for the respective target system. This
enables the system functions of the target system to be accessed (and con-
tains appropriate information in the form of online Help).
CoDeSys is supplied with the target support package for the CECX modu-
lar control system.
