1 The Festo_EasyIP.lib library
1.1 What is EasyIP?
EasyIP is a proprietary Ethernet protocol from Festo. EasyIP allows the simple connection of different
Festo controllers to form a network. EasyIP is a UDP-based point-to-point Ethernet protocol that uses port
995. EasyIP controllers can usually operate as both a client and server. Even devices that cannot function
as a server such as diagnostic devices or visualisation computers can operate with EasyIP. In theory, any
number of devices can be connected to an EasyIP network because it does not contain any logical
connections. Only the performance of the hardware determines the number of packages that can be sent
simultaneously or processed by the server.
EasyIP is implemented as an IEC library. The following table shows which operands are defined in EasyIP
and which can be exchanged via EasyIP in combination with a CoDeSys-based controller.
Supported operands
Description
Supported
Access via
Operand type
Range
Flags
Yes
%MW
1
[Target settings] [Memory
division] [Memory]
Inputs
Yes
%IW
2
[Target settings] [Memory
division] [Input]
Outputs
Yes
%QW
3
[Target settings] [Memory
division] [Output]
Registers
No
--
4
--
Timers
No
--
5
--
Strings
Yes
String table
11
Global declared constant:
MAX_STRING
Use the network variable exchange (see online Help, keyword "Network variables") to link
several CoDeSys-compatible controllers (e.g. several Festo CoDeSys controllers).
