System manual CECX / Ethernet option module CECX-C-ET
CECX-II 33-3
33.3 Description of the module
The CECX-C-ET is an option module for inserting in CPU modules. The
CECX-C-ET Ethernet option module can be integrated into a 10Mbit/s as
well as a 100Mbit/s Ethernet.
Information:
The module’s function is guaranteed only if it is used in a CPU module. The
module is not designed for connection with foreign modules.
The MAC-ID (unique physical address of a network card) is attached to the
inside of the module as sticker.
33.3.1 Front view
Ethernet
X5
CECX-C-ET front view
