System manual CECX / Digital output module CECX-D-14A-2
CECX-II 16-3
16.3 Description of the module
The CECX-D-14A-2 constitutes a digital output module for use in the CECX
modular control system.
16.3.1 Front view
000102030405060708091011121314151617
0V
+24V
DO0
DO1
DO2
DO3
DO4
DO5
DO6
DO7
0V
+24V
DO8
DO9
DO10
DO11
DO12
DO13
Pxxxxx-xxxxx
2
1
3
3
CECX-D-14A-2 front view
1.... Voltage supply for DO0 – DO7
2.....Voltage supply for
DO8 – DO13
3.... 14 digital outputs
