System manual CECX / Serial interface module CECX-S-2S1
CECX-II 28-9
28.8 Technical data
General
Supply voltage logic: 24 V DC from K Bus
5 V DC from K Bus
Addressing at K-Bus:
Via 16-digit address switch, on the side
Max. 4 modules possible (address switch position 4-F invalid)
Max. power consumption K Bus 24
V:
0 W
Max. power consumption K Bus 5 V: 0.4 W
Overvoltage category: II
Equipment class III according to EN 61131-2:2007
Environmental conditions
Operating temperature: +5 °C to +55 °C
Storage temperature: -40 °C to +70 °C
Relative humidity of air: 10 % to 95 % (non condensing)
Vibration resistance: according to IEC 61131-2:2007
Shock resistance: according to IEC 61131-2:2007
Interfaces
Interface type: RS-232-C, 9-pole male connector
Transmission media: shielded cable
Galvanic isolation: No
RS-232-C baud rates:
Adjustable via software,
Permitted Baud rates: 1200, 2400, 4800, 9600, 19200,
38400, 57600 and 115200 Baud
Dimensions:
Footprint:
Module height: 120 mm
Mounting depth: 100 mm
Front panel width: 22.5 mm
Module width:
(incl. K-Bus plug)
32.5 mm
Weight: 132 g
