System manual CECX / Temperature module CECX-E-4E-T-P1
CECX-II 23-10
23.6 Operating behavior
23.6.1 Response by the measurement inputs
Internally the CECX-E-4E-T-P1 measures the temperature value every 1
ms. The sliding mean value from the last 100 measurements (100 ms) is
calculated every 2 ms.
This value is available for the application at the hardware end point sys-
tem.TI0.
23.6.2 Behavior during a fault
23.6.2.1 Module errors
In case of a module error an internal watchdog monitor will be triggered.
The module signals the module error to the CPU module.
The CECX-E-4E-T-P1 module is no longer operative after a watchdog reset
and should therefore be replaced.
23.6.2.2 Sensor failure
The module identifies both a failure in the measurement line, as well as in
the reference currency line. The sensor failure is communicated to the CPU
Once the sensor failure has been corrected the status "Sensor failure" will
be automatically reset.
23.7 Disposal
23.7.1 Disposal of the module
• The symbol with the crossed-out waste container means that electrical
and electronic devices including their accessories must not be dis-
posed of in the household garbage.
• The materials are recyclable in accordance with their labeling. By dis-
posing of such used devices correctly, you can ensure that they can be
reused, their raw materials recycled or put to another use, and you will
be making an important contribution to the protection of our environ-
ment!
