System manual CECX / Ethernet option module CECX-C-ET
CECX-II 33-9
33.9 Technical data
Envirionmental conditions
Operating temperature: +5 °C bis +55 °C
Storage temperature: -40 °C bis 70 °C
Relative humidity of air: 10 % bis 95 % (nicht kondensierend)
Vibration resistance: Gemäß EN 61131-2:2007
Shock resistance: Gemäß EN 61131-2:2007
Interface to CPU module
Interface type: Media Independent Interface
Connection: CHAMP plug 30-pole
Power supply: 5 V
Module recognition: YES (Module given, YES/NO, no type recognized)
Ethernet interface
Ethernet interface: 10/100 Mbit/s LAN
Number: 1
Connection: Modular plug, 8-pin (RJ45 plug)
Mechanics
Structure: No casing; only front plate mounted on print
Protection class:
When the module is plugged into the CPU module, the CPU
module meets IP20
Weight: 23 g
