System manual CECX / Digital input module CECX-D-16E
CECX-II 15-3
15.3 Description of the module
The CECX-D-16E constitutes a digital input module for use in the CECX
modular control system.
15.3.1 Front view
000102030405060708091011121314151617
0V
n.c.
DI0
DI1
DI2
DI3
DI4
DI5
DI6
DI7
DI8
DI9
DI10
DI11
DI12
DI13
DI14
DI15
Pxxxxx-xxxxx
2
1
CECX-D-16E front view
1.... Reference potential
2.....16 digital inputs
(DI0 and DI1 interruptible)
Information
The type plate is stored on the module in an EEPROM and can be read out
by the application.
