System manual CECX / PROFIBUS Slave interface module CECX-F-PB-S-V1
CECX-II 26-8
26.6 Configuration
For configuration of the module, please see CoDeSys help under 'Configu-
ration of PROFIBUS modules'.
26.6.1.1 Setting the address
Since only one CECX-F-PB-S-V1 may be added to a CPU module, no ad-
dress setting is required.
26.7 7 Operating behavior
26.7.1 Start-up after Power-On
The module is passive and is configured and activated through the HOST.
26.7.2 Error response
Any module error is indicated by the STATUS-LED. Possible errors: See
chapter 26.4.1 Status LED (STATUS).
26.7.3 Watchdog
The CECX-F-PB-S-V1 has a internal watchdog. The process data must be
collected by the PROFIBUS-master within 50 ms. That implies a maximum
cycle time of 50 ms.
26.8 Disposal
26.8.1 Disposal of the module
• The symbol with the crossed-out waste container means that electrical
and electronic devices including their accessories must not be dis-
posed of in the household garbage.
• The materials are recyclable in accordance with their labeling. By dis-
posing of such used devices correctly, you can ensure that they can be
reused, their raw materials recycled or put to another use, and you will
be making an important contribution to the protection of our environ-
ment!
