Festo CECX-X-C1 Series User Manual

System manual CECX / Analog input/output module CECX-A-4E4A-V
CECX-II 21-3
21.3 Description of the module
The CECX-A-4E4A-V is an analog module for use in the CECX modular
control system.
21.3.1 Front view
000102030405060708091011121314151617
UREF
GND
GND
GND
+
-
AI0
+
-
AI1
+
-
AI2
+
-
AI3
AO0
AO1
GND
AO2
AO3
GND
2
1
CECX-A-4E4A-V front view
1.... 4 analog inputs 2 4 analog outputs
Information
The type plate is stored on the module in an EEPROM and can be read out
by the application.
