CECX modular control system
0..URef Single-ended input circuit, calibration standardized to
URef.
Status values as diagnosis information
The following status values are created for this module (example):
Possible error states (when status = TRUE)
Module status: module is defective or missing.
AI status: sensor failure detection
CECX-A-4A-V
Analog input/output module
4 analog outputs +/- 10V, resolution: 12 Bit
Module parameters
Name Value Description
Address Auto The address set on the hex switch on the module is
recognized and taken over automatically.
See chapter "Address setting for modules".
0 - F The address set here (specified in hexcode) must be
brought into agreement with the position of the address
switch on the module.
CECX-I 22
