System manual CECX / Serial option module CECX-S-S4
CECX-II 32-12
32.9 Technical data
Environmental conditions
Operating temperature: +5 °C to +55 °C
Storage temperature: -40 °C to +70 °C
Relative humidity of air: 10 % to 95 % (non condensing)
Vibration resistance: According to EN 61131-2:2007
Shock resistance: According to EN 61131-2:2007
Interface to CPU module
Interface type: 3.3 V TTL output of the UART
Connection: CHAMP plug 30-pole
Power supply: 5 V
Module recognition: YES (Module given, YES/NO, no type recognized)
CECX-S-S4
Interface type: RS-485-A/RS-422-A, 9-pole connector plug
Transmission media: shielded cable
Galvanic isolation: No
RS-485-A/RS-422-A Baud rates: To be set via software (from 1200 Baud to 115000 Baud)
Switching between RS-485-A and
RS-422-A:
To be set via software
Mechanics
Structure: No casing; only front plate mounted on print
Protection class:
When the module is plugged into the CPU module, the CPU
module meets IP20
Weight: 31 g
