System manual CECX / Analog input/output module CECX-A-4E4A-A
CECX-II 22-4
22.3.2 Accessories
22.3.2.1 Connector strip
Input/output signals: Standard male connectors with grid dimension 5.08
mm
The following female connectors are required:
2 blocks with 8 connections
1 block with 2 connections
Female connector Color Number Order no. Weidmüller
8-pole sw 2 BLZF 5.08/8 SN SW - 170775
2-pole sw 1 BLZF 5.08/2 SN SW - 170769
Information
Larger terminal blocks may be used to group multiple signals. The current
carrying capacity of the terminal block is thus, however, reduced (according
to derating curve of the terminal block manufacturer.)
The technical data for the terminals are contained in the technical data
sheet of the manufacturer of the female connectors.
