System manual CECX / Incremental encoder interface module CECX-C-2G2
CECX-II 27-21
Latch inputs
Number of inputs: 2
Response time latch input:
20 μs
Input type: Configuration as sink (acc. to EN 61131) or source input
Galvanic isolation: No
Time stamp for latch event
Resolution:
1 μs
Max. cycle time: 16 Bit counter -> unique up to 65ms cycle time
System interface
K-Bus Parallel bus interfaces, plug-in on side
Diagnosis possibilities
Sensor failure and sensor short circuit at 5 V differential input configuration
Zero pulse monitoring
Counter overflow
Track error: Signal frequence at inputs outside specifications (max. 250 kHz)
Dimensions:
Footprint:
Module height: 120 mm
Mounting depth: 100 mm
Front panel width: 22.5 mm
Module width:
(incl. K-Bus plug)
32.5 mm
Weight: 135 g
