System manual CECX / Ethernet option module CECX-C-ET
CECX-II 33-5
33.4.1 Inserting an option module
1) Turn off the power supply.
2) Remove dummy module.
3) Insert module in the correct position (labeling X5 and "Ethernet") into
the right slot.
Ethernet
X5
X3 X4 X5
EthernetSerial Interface
Inserting the CECX-C-ET option module into CP 23x module
