6. Close rack door
2. Identify faulty internal disk
3. Replace internal disk
4. Incorporate replaced internal disk into system
5. Confirm that there is no problem with
replaced FRU
Maintenance complete
1. Open rack door
Table 7-4
Active/hot replacement work procedure (for an internal disk in a RAID configuration)
Item Work procedure Reference
1 Opening the rack door
2 Identifying a faulty internal disk "14.2.9 Checking for a failed disk drive" in the Fujitsu
M10/SPARC M10 Systems System Operation and Administration
Guide
3 Replacing a faulty internal disk "Chapter 10 Maintaining the Internal Disks"
4 Incorporating the replacement internal disk
into the system
"14.2.10 Replacing a failed disk drive" in the
Fujitsu
M10/SPARC M10 Systems System Operation and Administration
Guide
5Confirming that there is no problem with
the replacement FRU
"4.2.2 Identifying a failure" - "Checking the FRU status"
6 Closing the rack door
Figure 7-3
Active/hot replacement flow (for an internal disk in a RAID
configuration)
