3. Release faulty internal disk from system
4. Replace faulty internal disk
5. Incorporate replaced internal disk into system
6. Confirm that there is no problem with
replaced FRU
7. Close rack door
Maintenance complete
2. Check operating condition of system and I/O
device usage status
1. Open rack door
Table 7-5
Active/hot replacement work procedure (for an internal disk not in a RAID configuration)
Item Work procedure Reference
1 Opening the rack door
2 Checking the operating condition of the
system and the I/O device usage status
"5.3 Checking the Operating Condition and Resource
Usage Status"
3 Releasing a faulty internal disk from the
system
"5.4.2 Enabling the removal of an I/O device" - "Enabling
the removal of an internal disk"
4 Replacing a faulty internal disk "Chapter 10 Maintaining the Internal Disks"
5 Incorporating the replacement internal disk "6.5.2 Incorporating an I/O device"
6 Confirming that there is no problem with
the replacement FRU
"4.2.2 Identifying a failure" - "Checking the FRU status"
7Closing the rack door
Figure 7-4
Active/hot replacement flow (for an internal disk not in a RAID
configuration)
Chapter 7 Maintenance Flow 117
