Table
7-7

Active/cold
replacement
work
procedure
(building
block
configuration
only)
Item
Work
procedure Reference
1 Opening
the
rack
door
2 Checking
the
operating
condition
of
the
system
and
the
I/O
device
usage
status
"5.3
Checking
the
Operating
Condition
and
Resource
Usage
Status"
3 Releasing
the
assignment
of
a
PCIe
card "5.4.1
Releasing
the
assignment
of
I/O
devices"
4
Releasing
the
chassis
requiring
maintenance
from
the
partition
"5.4.3
Releasing
a
chassis
requiring
maintenance
from
the
physical
partition"
5
Releasing
the
chassis
requiring
maintenance
from
the
system
"5.8.1
Releasing
of
the
SPARC
M10-4S
chassis
(possible
only
in
a
system
with
a
building
block
configuration)"
6 Enabling
access
to
the
FRU
requiring
maintenance
"5.9
Accessing
an
FRU"
7 Replacing
a
faulty
FRU See
the
removal
and
installation
procedures
in
the
maintenance
procedures
for
each
FRU
(Chapters
8
to
16).
"Chapter
8
Maintaining
the
PCI
Express
Cards"
"Chapter
9
Maintaining
the
CPU
Memory
Unit/Memory"
(*1)(*2)
"Chapter
10
Maintaining
the
Internal
Disks"
"Chapter
11
Maintaining
the
Fan
Units"
"Chapter
12
Maintaining
the
Power
Supply
Units"
"Chapter
13
Maintaining
the
PSU
Backplane
Unit/
Operation
Panel"
(*1)
"Chapter
16
Maintaining
the
XSCF
BB
Control
Cables"
"Chapter
17
Maintaining
the
XSCF
DUAL
Control
Cables"
8
Restoring
the
chassis
requiring
maintenance
"6.1
Restoring
the
Chassis"
9 Incorporating
the
chassis
requiring
maintenance
into
the
system
"6.2.1
Incorporation
of
the
SPARC
M10-4S
chassis
(possible
only
in
a
system
with
a
building
block
configuration)"
10 Diagnosing
the
chassis
requiring
maintenance
"6.3.1
Diagnosing
the
system
board"
(*3)
"6.3.2
Diagnosing
the
crossbar
unit
and
crossbar
cables"
11 Incorporating
the
chassis
requiring
maintenance
into
a
partition
"6.5.1
Incorporating
a
chassis
into
a
physical
partition"
12 Confirming
that
there
is
no
problem
with
the
replacement
FRU
"4.2.2
Identifying
a
failure"
-
"Checking
the
FRU
status"
13 Restoring
the
logical
domain "6.5.3
Restoring
the
logical
domain
to
the
pre-maintenance
state"
14 Closing
the
rack
door
*1
Simultaneous
replacement
of
the
CPU
memory
unit
and
PSU
backplane
unit
is
prohibited.
To
replace
the
CPU
memory
unit
and
PSU
backplane
unit,
first
replace
either
of
the
units
and
perform
the
work
in
"9.
Incorporating
the
chassis
requiring
maintenance
into
the
system."
Then,
return
to
"5.
Releasing
the
chassis
requiring
maintenance
from
the
system,"
and
replace
the
other
unit.
Lastly,
restore
the
system.
*2
If
a
CPU
memory
unit
lower
is
replaced
in
the
system
of
the
hardware
RAID
volume
in
a
hardware
RAID
configuration
using
internal
disks,
you
need
to
reactivate
the
hardware
RAID
volume
before
starting
Oracle
Solaris.
Start
Oracle
Solaris
on
the
control
domain
as
described
in
"11.
Incorporating
the
chassis
requiring
maintenance
into
a
partition."
For
details,
see
"14.2.11
Re-enabling
a
hardware
RAID
volume"
in
the
Fujitsu
M10/SPARC
M10
Systems
System
Operation
and
Administration
Guide.
*3
Normally,
the
testsb
command
is
executed
during
replacefru
command
processing.
However,
if
that
is
canceled,
diagnose
the
system
board
before
incorporating
the
chassis
requiring
maintenance
into
the
physical
partition.
Chapter
7

Maintenance
Flow 121
