1. Open rack door
4. Release chassis requiring maintenance from
partition
6. Enable access to FRU requiring maintenance
5. Release chassis requiring maintenance from
system
7. Mount installation part
8. Restore chassis requiring maintenance
9. Incorporate chassis requiring maintenance
into system
12. Confirm that there is no problem with the
replaced FRU
13. Restore logical domain
14. Close rack door
Installation complete
3. Check assignment status of PCIe card
2. Check operating condition of system and
I/O device usage status
11. Incorporate chassis requiring maintenance
into partition
10. Diagnose chassis requiring maintenance
Figure
7-16
Active/cold
addition
flow
(building
block
configuration
only)
Chapter
7
Maintenance
Flow 141
