Table 7-28
System-stopped/hot removal work procedure (for an internal disk or PCIe card)
Item Work procedure Referenc e
1 Opening the rack door
2 Switching the mode switch on the
operation panel to Service mode
"5.2 Switching the Mode Switch to Service Mode"
3 Checking the operating condition
of the system and the I/O device
usage status
"5.3 Checking the Operating Condition and Resource Usage Status"
4 Stopping the system "5.6 Stopping the Entire
System"
5 Lowering the cable support for
maintenance on a PCIe card
"5.9.2 Lowering the cable support"
6 Removing the target FRU See the removal procedure for each FRU
"Chapter 8 Maintaining the PCI Express Cards"
"Chapter 10 Maintaining the Internal Disks"
7 Securing the cable support after
maintenance on a PCIe card
"6.1.2
Fixing the cable support"
8Diagnosing the chassis requiring
maintenance
"6.3.1 Diagnosing the system board"
9 Confirming that there is no
problem with the chassis after the
removal
"4.2.2 Identifying a failure" - "Checking the FRU status"
10 Returning the mode switch on the
operation panel to Locked mode
"6.6 Returning the
Mode Switch to Locked Mode"
11 Starting the system "6.8 Starting the Entire System"
12 Closing the rack door
Chapter 7 Maintenance Flow 163
