1. Open rack door
3. Check operating condition of system and
I/O device usage status
4. Stop system
7. Remove target FRU
9. Incorporate chassis requiring maintenance
into system
6. Remove chassis requiring maintenance
5. Release chassis requiring maintenance
from system
10. Perform diagnosis test
12. Return mode switch to original mode
13. Start system
14. Close rack door
Removal complete
2. Switch mode switch
11. Confirm that there is no problem with
chassis after removal
8. Restore chassis requiring maintenance
Figure 7-29
System-stopped/cold removal flow (for a building block configuration)
