Table 7-30
System-stopped/cold removal work procedure (for a building block configuration)
Item Work procedure Referenc e
1 Opening the rack door
2 Switching the mode switch on the
operation panel to Service mode
"5.2 Switching the Mode Switch to Service Mode"
3 Checking the operating condition
of the system and the I/O device
usage status
"5.3 Checking the Operating Condition and Resource Usage Status"
4 Stopping the system "5.6 Stopping the Entire
System"
5 Releasing the chassis requiring
maintenance from the system
"5.8.1 Releasing of the SPARC M10-4S chassis (possible only in a
system with a building block configuration)"
6 Removing the chassis requiring
maintenance
"5.9 Accessing an FRU"
7 Removing the target FRU See the removal procedures for each FRU (Chapters 8 to 10).
"Chapter
8 Maintaining the PCI Express Cards"
"Chapter 9 Maintaining the CPU Memory Unit/Memory"
"Chapter 10 Maintaining the Internal Disks"
8 Restoring the chassis requiring
maintenance
"6.1 Restoring the Chassis"
9 Incorporating the chassis requiring
maintenance into the system
"6.2.1 Incorporation of the SPARC M10-4S chassis (possible only in
a system with
a building block configuration)"
10 Performing a diagnosis test "6.3.1 Diagnosing the system board" (*1)
"6.3.2 Diagnosing the crossbar unit and crossbar cables"
11 Confirming that there is no
problem with the chassis after the
removal
"4.2.2 Identifying a failure" - "Checking the FRU status"
12 Returning the mode switch on the
operation
panel to Locked mode
"6.6 Returning the Mode Switch to Locked Mode"
13 Starting the system "6.8 Starting the Entire System"
14 Closing the rack door
*1 The testsb command is executed during replacefru command processing. However, if that is canceled, diagnose the system board
before incorporating the chassis requiring maintenance into the physical partition.
