Table 2-7
Functions of the power switch (continued)
Icon Operation Description
If the system is stopped in
Locked mode:
Starts the system.
At this time, if a wait time for the air conditioning
facilities or a warm-up time is set on the XSCF,
the processing for waiting for the power-on of the
air conditioning facilities and the completion of
warm-up is omitted.
Long
press
(For 4 seconds or
more)
If the system has been
started in Service mode
(*1):
Perform the system shutdown process to stop the
system.
If the system startup
process is in progress in
Service mode:
Cancels the system startup process and then
stops the system.
If the system stop process
is in progress
in Service
mode:
Continues the system stop process.
If the system is stopped in
Service mode:
Operation is ignored.
Even a long press does not start the system.
If the system is stopped in
Locked mode:
Starts the system.
If a wait time for the air conditioning facilities or
a warm-up time is set
on the XSCF, the
processing for waiting for the power-on of the air
conditioning facilities and the completion of
warm-up is omitted.
If the system is not
stopped in Locked mode:
Operation is ignored.
*1 If the system has been started, it means that at least one physical partition has been powered on.
Table 2-8
Functions of the mode switch
Function Mode switch
Locked Service
Starting/Stopping the system
by the power switch
Only system startup is enabled. A long press
shuts down the
system.
Inhibition of break signal
reception
Enabled. Using the setpparmode
command, it is possible to specify
whether break signal reception is
allowed or inhibited for each physical
partition.
Disabled
Table 2-8 describes the functions of the mode switch.
Chapter 2 Understanding the System Components 23
