Connect the following cables to the system board:
1 Front panel cable to connector "FRONTPANEL1"
2 Front USB cable to connector "USB3.0 FRONT"
▶
If applicable, connect the ODD SATA cable to connector "SATA ODD" on the
system board.
▶
If applicable, connect the ODD power cable to connector X17 on the
backplane, see "Connecting a 3.5-inch HDD backplane" on page 145.
▶
If applicable, install the expansion card in slot 4, see "Installing an
expansion card" on page 229.
For the cable plan, see "Appendix B" on page 463.
▶
Carefully pull the front panel module into its bay and regard that the locking
mechanism snaps in (see circle).
CAUTION
▶
Ensure that none of the cables are strained or damaged!
Concluding steps
▶
"Installing the fan holder" on page
61
.
▶
"Installing the air duct" on page 59.
▶
"Reassembling" on page 51.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 57.
▶
"Verifying system information backup or restore" on page 72.
▶
Store the system information of your server on the Chassis ID EPROM
integrated into the front panel board. For more information on how to obtain
and use the Chassis ID Prom Tool, see "Using the Chassis ID Prom Tool"
on page 94.
▶
"Resuming BitLocker functionality" on page 88.
Front panel
RX2520 M5 Upgrade and Maintenance Manual 365
