Fujitsu PRIMERGY TX1310 M1

TX1310 M1 Upgrade and Maintenance Manual 117
Expansion cards and backup units
9.1.1 Equipping the PCIe slots
I For the latest information of the installing order, refer to your server’s
hardware configurator available online at the following address:
for the EMEA market:
http://ts.fujitsu.com/products/standard_servers/index.html
for the Japanese market:
http://jp.fujitsu.com/platform/server/primergy/system/
1. Graphic controller PCI bus type Max pcs per
system
Preferred slot
1 2 3
Nvidia NVS 300 PCIe x1 PCIe 1 2 3
2. PCI-Express
controller
PCI bus type Max pcs per
system
Preferred slot
1 2 3 4
Intel
®
Ethernet Server
Adapter i350-T2
PCIe 1 2 3 4 1
Intel
®
Gigabit CT Desktop
Adapter (LAN)
PCIe 2 1 2 3 4
