96 Upgrade and Maintenance Manual
TX1310 M1
Hard disk drives
7.3.3 Inserting the Easyclick rails in the bay
Figure 45: Inserting the Easyclick rails in the bay
Ê Push the Easyclick rails completely into the bay (1).
Ê Press the green handle outwards until it locks in place (2)
7.3.4 Concluding steps
Ê "Installing the side cover" on page 53
Ê "Connecting the server to the mains" on page 54
Ê "Switching on the server" on page 55
/
