196 Upgrade and Maintenance Manual
TX1310 M1
System board and components
Ê "Connecting the server to the mains" on page 54
Ê "Switching on the server" on page 55
Ê "Verifying the system time settings" on page 72
Ê If applicable, restore the BIOS settings manually.
14.3 Trusted Platform Module (TPM)
14.3.1 Installing the TPM
14.3.1.1 Preliminary steps
Ê "Shutting down the server" on page 40
Ê "Disconnecting the server from the mains" on page 41
Ê "Removing the side cover" on page 42
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Software: 5 minutes
Tools: – Bit screw driver
– TPM bit insert
(
*
)
(
*
)
For the Japanese market:
– TPM module fixing tool (S26361-F3552-L909)
