Fujitsu PRIMERGY TX1310 M1

TX1310 M1 Upgrade and Maintenance Manual 197
System board and components
14.3.1.2 Installing the TPM
Figure 146: TPM installation kit
Figure 147: TPM mounting location
1 TPM (Trusted Platform Module) 3 Special screw for TPM
2 TPM spacer
I The black TPM spacer is
not used in this server.
4 TPM bit insert for TPM special
screw
/
