Fujitsu PRIMERGY TX1310 M1

TX1310 M1 Upgrade and Maintenance Manual 223
Appendix
16.1.3 Server interior
Figure 163: Interior
Pos. Component
1 Expansion card slots
2 Processor / CPU heat sink / CPU fan
3 TPM board (if installed)
4 HDD 2
5 HDD 1
6 System fan 2 (FAN2 SYS on the SEL)
7 HDD 3
8 HDD 4
햲 햳
햻
햷
햴
햺
햹
햽햿
헀
햸
햾
햶햵
