TX1310 M1
Upgrade and Maintenance Manual 49
Basic hardware procedures
4.5.2 Installing accessible drives
4.5.2.1 Installing the optical disk drive (ODD)
Figure 10: Installing the optical disk drive
Ê Insert the optical disk drive into its installation bay and carefully push in until
it locks in place (1).
I Make sure that the fixation plate is attached on the left side of the
accessible drive.
