118 Upgrade and Maintenance Manual
TX1310 M1
Expansion cards and backup units
9.2 Handling slot brackets
9.2.1 Installing a slot bracket
Figure 64: Non-perforated slot bracket
Installing the slot bracket
Ê Place the controller on the mounting tabs on the slot bracket.
Ê Fasten the slot bracket to the controller with two M3 x 4.5 mm screws.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
1 Full height bracket non-perforated
