130 Upgrade and Maintenance Manual
TX1310 M1
Expansion cards and backup units
9.3.3 Replacing expansion cards
Note on network settings recovery
I When replacing network controllers or the system board, network
configuration settings in the operating system will be lost and replaced
by default values. This applies to all static IP address and LAN teaming
configurations.
Ensure to note down your current network settings before replacing a
network controller or the system board.
9.3.3.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 63
Ê "Shutting down the server" on page 40
Ê "Disconnecting the server from the mains" on page 41
Ê "Removing the side cover" on page 42
9.3.3.2 Removing an expansion card
Ê Remove the defective expansion card as described in section "Removing
expansion cards" on page 127.
Ê If the slot bracket on the defective expansion card is to be reused, remove it
from the expansion card as described in section "Removing a slot bracket"
on page 122.
9.3.3.3 Installing an expansion card
Ê If applicable, install a slot bracket on the new expansion card as described
in section "Installing a slot bracket" on page 118.
Ê Install the new expansion card as described in section "Installing expansion
cards" on page 123.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver (only for installing slot brackets)
