194 Upgrade and Maintenance Manual
TX1310 M1
System board and components
14.2 Replacing the CMOS battery
Safety notes
V CAUTION!
●
The CMOS battery must be replaced with an identical battery or with
a battery type recommended by the manufacturer.
●
Keep lithium batteries away from children.
●
Do not throw batteries into the trash can. Lithium batteries must be
disposed of in accordance with local regulations concerning special
waste.
●
For further safety information, please refer to section "Environmental
protection" in the corresponding operating manual.
●
Ensure to insert the CMOS battery the with the positive pole
facing up!
14.2.1 Preliminary steps
Ê "Shutting down the server" on page 40
Ê "Disconnecting the server from the mains" on page 41
Ê "Removing the side cover" on page 42
Ê Remove all accessible drives as described in section "Removing accessible
drives" on page 43.
Ê "Removing the front cover" on page 46
Ê "Removing the HDD cage" on page 56
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver; recommended: tooth pick
