46 Upgrade and Maintenance Manual
TX1310 M1
Basic hardware procedures
4.4.3 Removing the front cover
Figure 8: Removing the front cover
Ê Disengage the three locking tabs on the front cover by pulling it forwards (1).
Ê Carefully rotate open (2) and unhook the front cover (3).
햲
햲
햲
햳
햴
