TX1310 M1
Upgrade and Maintenance Manual 43
Basic hardware procedures
4.4.2 Removing accessible drives
4.4.2.1 Disconnecting the optical disk drive (ODD)
Figure 5: Disconnecting cables from the optical disk drive
Ê Disconnect all cables from the optical disk drive.
1 Power cable connector P8
2 SATA cable
/
