Fujitsu PRIMERGY TX1310 M1

48 Upgrade and Maintenance Manual TX1310 M1
Basic hardware procedures
4.5.1 Installing the front cover
Figure 9: Installing the front cover
Ê Hook the three tabs on the front bezel into the notches in the chassis (1).
Ê Carefully close the front bezel (2). Make sure that all three locking latches
properly engage (3).
햲
햲
햲
햳
햴
햴
햴
