TX1310 M1
Upgrade and Maintenance Manual 97
Hard disk drives
7.4 Replacing a 3.5-inch HDD
V CAUTION!
All hard disk drives must be uniquely identified so that they can be
reinstalled in their original mounting locations later. If this is not done,
existing data can be lost.
7.4.1 Preliminary steps
Ê "Shutting down the server" on page 40
Ê "Disconnecting the server from the mains" on page 41
Ê "Removing the side cover" on page 42
Ê "Locating the defective component" on page 39
Only applicable for removing intact hard disk drives:
Ê Before removing a non-defective hard disk drive, put the hard disk drive into
"Offline" mode using your RAID configuration software.
I For further information, please refer to the "ServerView Suite RAID
Management" user guide.
7.4.2 Removing the defective 3.5-inch HDD
Ê Remove the hard disk drive as described in section "Removing a 3.5-inch
HDD" on page 93.
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less
