136 Upgrade and Maintenance Manual
TX1310 M1
Main memory
10.2 Installing memory modules
10.2.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 63
Ê "Shutting down the server" on page 40
Ê "Disconnecting the server from the mains" on page 41
Ê "Removing the side cover" on page 42
10.2.2 Installing a memory module
Ê Identify the correct memory slot according to the mounting order described
in section "Memory sequence" on page 134.
Figure 81: Installing memory modules (A)
Ê Press out the securing clip at each end of the memory module connector.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
