160 Upgrade and Maintenance Manual
TX1310 M1
Accessible drives
12.1 Basic information
Mounting order for accessible drives
The server offers two 5.25-inch accessible drive bays for optical disk drives and
backup drives.
Figure 103: Accessible drive bays
Sequence Accessible drive Bay Max. #
1
Optical disk drive
or slimline optical disk drive
Bay 1 1
2 RDX backup drive Bay 2 1
Table 5: Accessible drive mounting sequence
햲
햳
