TX1310 M1
Upgrade and Maintenance Manual 187
Front panel and front USB
13.2 Replacing the front USB module
13.2.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 63
Ê "Shutting down the server" on page 40
Ê "Disconnecting the server from the mains" on page 41
Ê "Removing the side cover" on page 42
Ê Remove all accessible drives as described in section "Removing accessible
drives" on page 43.
Ê "Removing the front cover" on page 46
Ê "Removing the HDD cage" on page 56.
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
