TX1310 M1
Upgrade and Maintenance Manual 175
Accessible drives
Figure 122: Removing the slide-in unit
Ê Press the locking latch in the direction of the arrow (1) and press out the
slide-in unit from behind (2).
Ê Pull the slide-in unit out of its bay.
12.3.4 Removing a backup drive
Ê Remove the backup drive as described in section "Disconnecting the
backup drive" on page 44.
