TX1310 M1
Upgrade and Maintenance Manual 179
Accessible drives
Figure 127: Attaching the fixation plate to the optical disk drive
Ê Attach the fixation plate on the left side of the new optical disk drive.
Ê Install the new optical disk drive as described in section "Installing an optical
disk drive (ODD)" on page 164.
12.4.3 Replacing a slimline optical disk drive (ODD)
Ê Remove the slide-in unit as described in section "Removing a slimline
optical disk drive (ODD)" on page 174.
