TX1310 M1
Upgrade and Maintenance Manual 177
Accessible drives
Figure 125: Installing the dummy drive in bay 2
Ê Insert the dummy drive in bay 2 and carefully push it in until it locks in place.
I The dummy drive is a little harder to insert than an ODD and the bezel of
the drive is touching the front panel.
12.3.6 Concluding steps
Ê Remove the fixation plates from the removed accessible drives.
Ê Secure the fixation plates on the chassis.
Ê "Installing the side cover" on page 53
Ê "Connecting the server to the mains" on page 54
Ê "Switching on the server" on page 55
Ê "Verifying and configuring the backup software solution" on page 69
Ê "Enabling BitLocker functionality" on page 74
