178 Upgrade and Maintenance Manual
TX1310 M1
Accessible drives
12.4 Replacing accessible drives
12.4.1 Preliminary steps
Ê "Disabling BitLocker functionality" on page 63
Ê "Removing backup and optical disk media" on page 64
Ê "Verifying and configuring the backup software solution" on page 65
Ê "Shutting down the server" on page 40
Ê "Disconnecting the server from the mains" on page 41
Ê "Removing the side cover" on page 42
12.4.2 Replacing an optical disk drive (ODD)
Ê Remove the defective optical disk drive as described in section "Removing
an optical disk drive (ODD)" on page 173.
Figure 126: Removing the fixation plate
Ê Remove the fixation plate from of the left side of the optical disk drive.
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: Phillips PH0 / (+) No. 0 screw driver
