TX1310 M1
Upgrade and Maintenance Manual 217
15 Cables
15.1 Overview cables
No. Part number Description From - to
C1 Component of PSU CBL_Power_16
from On/Off button and HDD
access LED to system board
C2 T26139-Y4012-V101 SATA power 5HDD cable from all drives to system board
C3 T26139-Y3942-V1 Power adapter SATA to 2x
PATA (4pins)
from power cable to backup drive
C4 T26139-Y3990-V201 LTG PWR SATA SL
power adapter cable for slimline
drive
C10 T26139-Y4001-V211 CBL_Frontpanel_LED from Front panel to LED
C12 T26139-Y3999-V501 CBL_Front_USB
from system board to USB front
connectors
C20 T26139-Y4028-V101 SATA data ODD cable
from optical disk drive to system
board
C21 T26139-Y4028-V152
SATA data HDD 3.5-inch
cable (red)
from HDD 1/2 to system board
C22 T26139-Y3958-V107
SATA data HDD 3.5-inch
cable (grey)
from HDD 3/4 to system board
C26 T26139-Y4039-A80 USB 3.0 cable U
SB 3.0 to backup drive RDX
